By adopting a stirring motor system, stable coating is possible even with a small amount (minimum 200g).（AXRⅡ100ST）
Since the purchased paint can be set in the paint carton as it is in the box, color change work can be done easily.（AXRⅡ100DF）
It has high paint agitation power and is excellent in discharge performance for paint with high specific gravity such as metallic paint.（AXRⅡ100FB）
The electrostatic controller displays the main coating parameters (gun voltage, current, air flow rate, and discharge rate) independently, greatly improving visibility and operability.
The gun’s built-in select switch allows you to increase or decrease the discharge amount and switch between 3 mode recipes at the gun’s hand, greatly improving workability.
|
Model |
AXRⅡ-100DF 〈AXRⅡ-200DF〉 |
AXRⅡ-100ST |
AXRⅡ-100FB |
|---|---|---|---|
| Hand gun Model | ECDm | ||
| Charging method | Dual electric field method | ||
| Maximum applied voltage |
-80kV |
||
|
Amount of paint discharge (1 gun) |
50~350g/min（Depend on powder, hose length and others） |
||
| Hand gun weight | 570g（without cable） | ||
| Electric controller model | BPS900m | ||
| Input power source (JAPAN) | AC100V 50Hz/60Hz | ||
| Current consumption | 0.7A〈1.2A〉 | 1.0A〈1.5A〉 | 0.5A〈1.0A〉 |
| Maximum air consumption |
1gun 270L/min（ANR）〈540L/min（ANR）〉 |
||
| Air connection diameter | φ10mm | ||
|
Input air pressure |
0.5MPa～0.6MPa Recommend pressure is 0.5MPa |
||
|
Powder capacity |
Box fludized flow 15kg 1carton |
Hopper and Agitator flow |
Tank fludized flow |
| Unit size (W×D×H) |
450×855×1135mm |
450×1171×1137mm |
510×839×1135mm |
| Unit weight | 43kg〈53kg〉 | 63kg〈73kg〉 | 53kg〈63kg〉 |
※<2 guns Type>
※Nozzles and hoses are not included with the unit. It will be ordered separately according to the specifications.
No.427
Oct., 2023
Powder coating of Fire Extinguisher Box
- Used paint:
- Powder paint
Learn more
Introduction : A new coating plant was established to bring previously outsourced coating operation in-house, and an automated electrostatic powder coating system was introduced.
Benefits :
1. Automation stabilized the quality and reduced coating defects.
2. The high coating efficiency of ECXa and the recovery＆reuse of paint significantly reduced the amount of paint used, contributing to cost reductions.
3. The transparent resin booth panel offers superior visibility and maintainability, improved the environment at the coating site.
Return to overview
No.424
Jul., 2023
Electrostatic coating for Bed frame
- Used paint:
- Liquid paint,Powder paint
Learn more
Introduction : A new system was introduced with the founding in May 2023.
Benefits :
1. Liquid automatic coating gun and liquid hand gun enabled high coating efficiency and atomization.
2. The latest electrostatic powder coating hand gun provides very little powder fall-off and high-quality coating even in thick coatings. Easily coat onto corners and weld angles.
3. More than 10% reduction in the amount of paint used than the previous model can be expected.
Return to overview
No.423
Apr., 2023
Powder coating for Steel-Rack * *
- Used paint:
- Powder paint
Learn more
Introduction : The company mainly manufactures and sells steel racks for distribution and book storage equipment. Due to the increasing orders for powder finishing and environmental measures, the solvent booth was removed and a powder coating system was introduced.
Benefits :
1. A powder gun that achieves excellent coating efficiency reduces the amount of paint used by about 20%.
2. The waste powder became less than 1% from about 20% of the amount of paint used.
3. The productivity is improved and correction frequency is drastically reduced.
4. The quality has been stabilized by the advance of the automation.
Return to overview
